• CoolingLiquid
  • Top Speed26 mph (41 km/h) *Adjustable with accessories
  • Front/Rear Brakes4-Wheel Hydraulic Disc with Dual-Bore Front Calipers
  • Hitch TypeStandard 2 in (5 cm) Receiver
  • Adjustable Driver SeatNot Equipped
  • Front Suspension9 in (22.9 cm)
  • Horsepower24.5 HP
  • Maintenance Interval200 Hours (50 Hour initial)
  • Payload Capacity1,900 lbs (862 kg)
  • Box Capacity1,250 lb (567 kg)
  • Lighting55W low/ 60W high, LED Tail
  • Person Capacity2
  • Other Standard FeaturesHorn, Backup Alarm
  • Transmission/Final DriveAutomatic PVT H/L/N/R/P; Shaft
  • Tilt SteeringStandard
  • Wheelbase85 in (215.9 cm)
  • HubsFront: Steel; Rear: Ductile Iron
  • Cylinders Displacement898 cc
  • Wheels12 x 6 HD Steel - Gloss Black
  • Rear Suspension9 in (22.9 cm)
  • Turning Radius112 in (284 cm)
  • Hitch Towing Rating2,500 lb (1,134 kg)
  • InstrumentationAll Digital Gauge, Speedomoter, Odometer, Tachometer, 2 Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, Engine Temperature, Hi-Temp Light, Clock, Clutch Belt Slip Warning, Glow Plug Indicator, Low Oil Pressure Indicator, Seat Belt Indicator, Parking Brake Engaged Alarm
  • Parking BrakePark in Transmission + Separate Mechanical Parking Brake Standard
  • Electronic Power SteeringOptional
  • Overall Vehicle Size (L x W x H)126 x 62.5 x 75 in (320 x 159 x 191 cm)
  • Ground Clearance11 in (27.9 cm)
  • Drive System TypeOn-Demand 4x4
  • Fuel Capacity11.5 gal (43.5 L)
  • Estimated Dry Weight1,627 lb (738 kg)
  • Fuel System/BatteryMechanical Injection
  • Bed Box Dimensions (L x W x H)43.5 x 54 x 11.5 in (110.5 x 137 x 29 cm)
  • Engine Type3-Cylinder Kubota® Diesel
  • Rear Tires26 x 10-12 Duro® DI-2042 Power Grip (M/T)
  • Front Tires26 x 10-12 Duro® DI-2042 Power Grip (M/T)
  • Air IntakeFront Air Intake with Donaldson® Cyclonic Air Filter
  • Seat CoveringKevlar®-Backed Vinyl (Grey)
  • Cargo SystemLock & Ride®
