Key Features & Specs

Power to Handle Your Toughest Applications


A versatile lift truck designed for indoor and outdoor use, this truck series is ideally suited for a wide variety of applications such as industrial machinery, lumber yards, sawmills and concrete precast.

The H135-155FT series is configured to provide the right lift truck for your application. Multiple powertrain combinations assure your cost of operations will be lowered. Each configuration offers improved efficiency, advanced dependability, and simple serviceability. Pacesetter VSM industrial onboard computer manages truck operation to maintain world-class dependability to maximize uptime.

  • CANbus communications network reduces wiring complexity, providing superior dependability.
  • The H135-155FT series features multiple powertrain configurations that provide improved efficiency, while enhancing reliability and superior serviceability to reduce your operating costs.
  • Superior ergonomic design allows for easy driver access, more foot and leg room, excellent visibility and two choices of hydraulic controls enable your operator to maximize productivity.
  • Patented DuraMatch™ transmission provides breakthrough features that include the Auto Deceleration System, controlled rollback on ramps and controlled power reversals to move loads more efficiently with less operator fatigue and product damage.
  • + Expand All
  • - Close All
  • ModelTable
    Model Load Capacity (lbs) Engine Transmission Maximum Travel Speed (mph) Maximum Lift Speed (ft/min)
    H135FT 13500 Standard: PSI 4.3L V6 LPG Optional: Kubota 3.8L DOC Tier 4 Final Turbodiesel Optional: Kubota 3.8L High Output Tier 4 Final Turbodiesel Standard: 2-Speed Powershift Optional: 3-Speed Techtronix 332 15.2 102
    H155FT 15500 Standard: PSI 4.3L V6 LPG Optional: Kubota 3.8L DOC Tier 4 Final Turbodiesel Optional: Kubota 3.8L High Output Tier 4 Final Turbodiesel Standard: 2-Speed Powershift Optional: 3-Speed Techtronix 332 15.2 90
    H155FTS 15500 Standard: PSI 4.3L V6 LPG Optional: Kubota 3.8L DOC Tier 4 Final Turbodiesel Optional: Kubota 3.8L High Output Tier 4 Final Turbodiesel Standard: 2-Speed Powershift Optional: 3-Speed Techtronix 332 15.2 90
  • Weight: lbs
  • Capacity: 13,500 - 15,500 lbs
  • Max Height: 232
  • Type: PNEUMATIC TIRES FORKLIFT
  • Series Title: H135-155FT, H155FTS
  • Max Weight: 15500 lbs
