Papé Material Handling

20AM

JLG
Vertical Mast Lifts

Find Your Nearest Location

Find Location

Your Preferred Store

Change location Change location

Key Features & Specs

Key Specs

Platform Height: 20 ft 5 in. / 6.22 m
Machine Width: 2 ft 5 in. / 0.74 m

Key Features

Most rigid mast in the industry for operator comfort and stability
Six-wheel design for improved maneuverability
Long battery duty cycles and an automatic charger for more productivity

Long battery duty cycles and an automatic charger for more productivity
Most rigid mast in the industry for operator comfort and stability
Six-wheel design for improved maneuverability

Specifications
Documents

Machine Weight-DC: 860 lb / 390.09 kg
Platform Dimension A: 2 ft 2 in. / 0.66 m
Platform Capacity: 350 lb / 158.76 kg
Platform Dimension B: 2 ft 2 in. / 0.65 m
Machine Width: 2 ft 5 in. / 0.74 m
Working Height: 26 ft / 7.92 m
Outrigger Footprint Length: 5 ft 2 in. / 1.57 m
Platform Height: 20 ft 5 in. / 6.22 m
Outriggers or Stabilizers: Yes
Machine Length: 3 ft 11 in. / 1.19 m
Machine Weight-AC: 740 lb / 335.66 kg
Wheel Size - Front Caster: 6 x 2"
Wheel Size - Rear: 10 x 2"
Outriggers Up Max Lift Height: 20.4 ft / 6.22 m
Outrigger Footprint Width: 4 ft 5 in. / 1.35 m
Ground Entry Height: 1 ft 7 in. / 0.48 m
Machine Height: 6 ft 6 in. / 1.97 m

Documents

Equipment Document
