    Chassis Options

    • Tow package

    Tire Options

    • S-60 XC Trax or S-65 XC Trax: Quadra Track System
    • Rough terrain, foam-filled tires (petroleum based)
    • Rough terrain, non-marking, foam-filled tires (water based)
    • Rough terrain, non-marking, foam-filled tires  (petroleum based)

    Engine Options

    • 60 hp Ford MSG425, gas/LPG Dual Fuel (not available on S60/65 Trax)
    • 74 hp Deutz Tier 4f TD2.9L4, turbo diesel (standard with Trax)
    • Diesel intake air pre-cleaner
    • LPS Fire protection rating: Ford engine only and requires LP only operation
    • Cold weather kit:  5W-40 synthetic engine oil, oil pan heater, battery heater and hydraulic tank heater
    • Ford engine gauge package: oil pressure, temperature and voltage

    Lift/Turntable Options

    • Specialty hydraulic oil (60 gal - cold weather, fire resistant, or biodegradable)
    • LPG tank, 33.5 lb. capacity: Ford engine only
    • Second battery
    • Hostile environment kit: cylinder bellows, boom wiper seals, platform and ground control box covers
    • Deluxe hostile environment kit: hostile environment kit, ring gear guard, cable track hose cover, air pre-cleaner

    Platforms

    • 4 ft. front-entry steel platform
    • 6 ft. dual entry or 8 ft. tri entry platform with ½ height mesh inserts and side swing gate
    • 6 ft. dual entry platform with side swing gate

    Platform Options

    • Lift Power™ 3kW AC generator, 110V/60Hz or 220V/50Hz
    • Air line to platform: ½ in. inner diameter
    • Aircraft protection kit:  platform foam padding and padded disable system
    • Aircraft protection kit: with swing gate
    • Light package: 2 chassis mounted drive lights and 2 platform mounted work lights
    • Lockable platform and ground control box covers
    • Panel cradle package
    • Platform auxiliary top rail
    • Thumb rocker steering
    • Lift Power™ 12kW Welder - Select Lincoln or Miller
    • Lift Power™ 12kW Welder Ready package
    • Traveling fall arrest anchor system: requires 6ft platform
    • Traveling fall arrest anchor system: requires 8ft platform
  • Below Ground Reach5 ft 7 in | 1.70 m
  • Max Horizontal ReachS-60 XC, 50 ft 10 in / S-65 XC, 54 ft 2 in | S-60 XC, 15.49 m / S-65 XC, 16.51 m
  • Machine Width and Length8 ft 2 in, 31 ft 11 in | 2.49 m, 9.73 m
  • Platform Capacity660 lb Unrestricted, 1,000 lb Restricted | 300 kg Unrestricted, 454 kg Restricted
  • Max Platform HeightS-60 XC, 59 ft 8.5 in / S-65 XC, 65 ft 1 in | S-60 XC, 18.20 m / S-65 XC, 19.84 m
