460SJ

  • JLG
  • Telescopic Boom Lift

Find Your Nearest Location

Find Location
Your Preferred Store
Change location Change location
Request Quote
Key Features & Specs

Key Specs

  • Platform Height: 46 ft / 14.02 m
  • Platform Capacity - Unrestricted: 600 lb / 272.16 kg
  • Horizontal Outreach: 39 ft / 11.89 m

Key Features

  • Improved multifunction capability increases productivity
  • New hood design provides more durability and serviceability
  • Larger capacity at 600 lb
  • Larger capacity at 600 lb
  • New hood design provides more durability and serviceability
  • Improved multifunction capability increases productivity
  • Ground Clearance: 1 ft / 0.31 m
  • Transport Length: 29 ft 3 in. / 8.91 m
  • Maximum Ground Bearing Pressure: 60 psi / 4.20 Kg/cm2
  • Swing Type: Continuous
  • Drive Speed - 4WD: 4.5 mph / 7.24 km/h
  • Platform Dimension A: 3 ft / 0.91 m
  • Machine Weight: 16600 lb / 7529.63 kg
  • Engine Type - Diesel: Deutz D2.9L4 Tier 4 Final 49 hp 36.4 kW
  • Tire Size: 12 x 16.5 Pneumatic Lug Tread Tires
  • Capacity - Hydraulic Reservoir: 36 gal. / 136.27 L
  • Horizontal Outreach: 39 ft / 11.89 m
  • Tailswing: 2 ft 10 in. / 0.86 m
  • Horizontal Jib Rotation: 0 Degrees
  • Platform Height: 46 ft / 14.02 m
  • Auxiliary Power: 12 Volts DC
  • Gradeability - 4WD: 45 %
  • Jib - Range of articulation: 130 Degrees
  • Platform Dimension B: 8 ft / 2.44 m
  • Platform Capacity - Unrestricted: 600 lb / 272.16 kg
  • Machine Width: 7 ft 7 in. / 2.31 m
  • Turning Radius - Outside: 15 ft 11 in. / 4.84 m
  • Engine Type - Dual Fuel: GM Vortec 3000 MPFI 82 hp 61 kW
  • Swing: 360 Degrees
  • Machine Height: 8 ft 1 in. / 2.47 m
  • Capacity - Fuel Tank: 22 gal. / 83.28 L
