20MSP

  • JLG
  • Stock Pickers

Find Your Nearest Location

Find Location
Your Preferred Store
Change location Change location
Request Quote
Key Features & Specs

Key Specs

  • Platform Height: 19 ft 5 in. / 5.92 m
  • Machine Width: 2 ft 6 in. / 0.75 m

Key Features

  • Elevate and descend at various speeds
  • Zero turning radius for superior maneuverability
  • Built-in automatic charger for less downtime on the job
  • One-hand operation for increased operator comfort
  • Driveable at full height for increased efficiency
  • Elevate and descend at various speeds
  • Driveable at full height for increased efficiency
  • Built-in automatic charger for less downtime on the job
  • Zero turning radius for superior maneuverability
  • One-hand operation for increased operator comfort
  • Batteries: 2 Sealed 100 amp-hr Glass Mat (AGM)
  • Machine Length: 4 ft 6 in. / 1.36 m
  • Wheel Size - Front Caster: 8 x 2.5"
  • Drive System: 4 Brush Direct Electric
  • Platform Capacity: 400 lb / 181.44 kg
  • Machine Width: 2 ft 6 in. / 0.75 m
  • Platform Dimension B: 2 ft 4 in. / 0.71 m
  • Maximum Lift Height: 19.4 ft / 5.91 m
  • Drive Speed - Platform Elevated: 0.6 mph / 0.97 km/h
  • Platform Height: 19 ft 5 in. / 5.92 m
  • Ground Clearance: 2 in. / 0.05 m
  • Platform Dimension A: 4 ft / 1.22 m
  • Gradeability: 20 %
  • Drive Speed - Platform Lowered: 3.5 mph / 5.63 km/h
  • Wheel Size - Rear: 12.62 x 4"
  • Ground Entry Height: 1 ft 6 in. / 0.46 m
  • Machine Height: 6 ft 6 in. / 1.98 m
  • Working Height: 25 ft 5 in. / 7.75 m
  • Machine Weight: 2425 lb / 1099.96 kg
