• Platform Dimension B2 ft 6 in. / 0.76 m
  • Slope Tolerance12 °
  • Machine Width2 ft 7 in. / 0.79 m
  • Machine Weight5071 lb / 2300.17 kg
  • Outrigger Footprint Length10 ft 5 in. / 3.18 m
  • Fuel Tank Capacity - Gasoline1.5 gal. / 5.68 L
  • Jib - Range of articulation89 Degrees
  • Outriggers or StabilizersYes
  • Machine Length14 ft 10 in. / 4.52 m
  • Horizontal Outreach23 ft / 7.01 m
  • Engine Type - GasolineHonda GX440 15 hp
  • Track Length4 ft 1 in. / 1.24 m
  • Maximum Ground Bearing Pressure9.7 psi / 0.68 Kg/cm2
  • Platform Dimension A4 ft 10 in. / 1.47 m
  • Platform Height49 ft / 14.94 m
  • Engine Type - Electric100Ah 48V Lithium-Ion
  • Ground Bearing Pressure - Outriggers35.5 psi / 2.49 Kg/cm2
  • Swing TypeNon-Continuous
  • Platform Capacity500 lb / 226.80 kg
  • Swing360 Degrees
  • Machine Height6 ft 7 in. / 1.99 m
  • Gradeability28 %
